HIKMICRO Pocket1 Thermal camera

HIKMICRO Pocket1 Thermal camera

Product Description







HIKMICRO Pocket Series is equipped with a high-resolution HIKMICRO VOx detector, an 8 MP optical camera, and a 3.5” LCD touch screen. It helps you quickly and efficiently locate the hidden problems and accurately measure abnormal temperature. The wide temperature range of -20°C to 400°C is ideal for building inspection, HVAC, electrical, and mechanical equipment maintenance. The 25 Hz frame rate keeps up with fast inspections, and the Wi-Fi function allows the Pocket to share images in real time. The Pocket Series is a powerful thermography tool in your pocket, so it is always there whenever you need it.

Innovative Macro Mode
Using a clip-on macro lens, the Pocket Series cameras can see details as small as 500 microns and allow you to take accurate temperature readings on small objects, such as components on printed circuit boards or assemblies.

High Image Quality
A highly sensitive Vox 256 x 192 (49,152 pixels) detector (NETD < 40 mK ) provides a distinct thermal image of the target.

Rugged & Durable Design
IP54 rated for protection against water and dust. Featuring 2-meter (6.6ft) drop protection, suitable for industrial use.

3.5”LCD Touch Screen
View the details of your target from different angles on the large, class-leading 3.5” LCD Touch Screen.

4 Image Modes / 7 Color palettes
Thermal, Fusion, PIP, and Optical modes to suit your preferred view 7 color palettes give different image display options.

Faster Troubleshooting
Built-in speaker and flash light give the operator audio and visual alerts to high temperatures.
Full-screen measurement using different user presets checks everywhere instantly.

On-camera Recording
Built-in 16GB internal memory provides onboard recording and playback.

Fast Communication
Connect (Wi-Fi or Hotspot) to HIKMICRO Viewer App for transmitting pictures from camera to mobile phone. Analyze, share images and generate reports in real-time on-site.

Multiple Level & Span Modes
Three Level & Span modes (manual, automatic, and 1-Tap) help you instantly improve image contrast and highlight potential problems.

Key Feature
Thermal resolution: 192 × 144 (27,648 pixels), NETD: < 40 mK (@ 25°C, F# = 1.0)
Accurately measure temperature from -20°C to 400°C (-4°F to 752°F)
Accuracy: Max. (± 2°C/3.6°F, ± 2%)
25 Hz image frequency
Thermal, Fusion, PIP, Visual, and Blending modes
Manual, automatic, and 1-Tap level and span
High temperature alarm
Built-in 16 GB memory
LED work light
1.0x to 4.0x continuous digital zoom
8 MP visual camera
Up to 4 hours continuous running

Infrared Image
IR Resolution 192 × 144 (27,648 pixels)
NETD < 40 mK (@ 25°C, F#=1.0)
Image Frequency 25 Hz
Detector Pitch 12 μm
Spectral Range 7.5 to 14 μm
Focal Length 3.5 mm
F-number F1.1
Field of View (FOV) 37.5° × 28°
Spatial Resolution (IFOV) 3.43 mrad
Min. Focus Distance 0.3 m (0.98 ft)
Focus Mode Focus Free

Image Display
Visual Camera 3264 × 2448 (8 MP)
Display 640 × 480 Resolution, 3.5" LCD Touch Screen with auto-rotation
Screen Brightness Manual
Digital Zoom 1.0x to 4.0x continuous
Color Palettes White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Image Modes Thermal/Visual/Fusion/PIP/Blending

Measurement and Analysis
Object Temperature Range -20°C to 400°C (-4°F to 752°F )
Accuracy Max. (± 2°C/3.6°F, ± 2%), for the ambient temp. 15°C to 35°C (59°F to 95°F) and object temp. above 0°C (32°F)
Measurement Tools Center Spot, Hot Spot, Cold Spot
Level and Span Mode Auto/Manual/1-Tap Touch-screen

Data Storage and Communication
Storage Media Built-in 16 GB flash memory
Image Storage Capacity Approx. 60,000 Images
Annotations Text note: max. 200 characters
Video Storage Capacity Approx. 54 hours Video
File Format MP4 video

General
Wi-Fi 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth 4.2
USB Interface USB Type-C
LED Light Yes
Battery Type Rechargeable Li-ion battery
Battery Operating Time Approx. 4 hours
Battery Charging Time Approx. 2.5 hours fully charged
Protection Level IP54
Drop Test Height 2 m (6.56 ft)
Working Temperature Range -10°C to 50°C (-4°F to 122°F)
Storage Temperature Range -20°C to 60°C (-4°F to 140°F)
Relative Humidity < 95% non-condensing
Weight Approx. 218 g (0.481 lb)
Dimension 138.5 mm × 85.2 mm × 23.6 mm (5.45" × 3.35" × 0.93")
Tripod Mounting UNC ¼”-20
