VALCOM T7T Smart electronic temperature transmitters

Product Description

T7T series are Smart electronic transmitters with 4 ÷ 20 mA output and HART® digital communication protocol.
Configurations and adjustments can be made locally by means of push buttons and display or remotely using HART® protocol compatible communicators.

The transmitters are intended for direct mounting on pipe or tank with or without thermowell. For remote sensor version are supplied a bracket for wall or for 2” stand pipe mounting is also supplied.

Temperature measurement
Installation on chemical, Oil & Gas, pharmaceutical, alimentary, marine plants etc
Installation in areas with persistence of potentially explosive mixtures

Field of Application:Flow & Density, Level Continuous & On/Off, Other Measures, Pressure & Differential Pressure, Temperature
Typology:Temperature
Measure Principle:Thermoresistance
Measuring Range:Nipple-Union-Nipple: Tmax = 150 Deg C , Remote: Tmax = 350Deg C or 500 Deg C, Standard: -40 Deg C ~ +85Deg C
Process Connection:1/2" NPT-M, Flanged Thermowell, Screwed Thermowell
Process Temperature:Nipple-Union-Nipple: -40 Deg C ~ +150 Deg C , Remote: -40 Deg C ~ +500 Deg C , Standard: -40 Deg C ~ +85 Deg C
Accuracy Class:IEC 60770
Solution:Chemical & Pharmaceutical, Food & Beverage, Marine, Pulp & Paper, Water & Wastewater
