Hawk Measurement Gladiator G3 Microwave Switch

Product Description

The Gladiator Gen 3 Microwave Switch can be used for blockage detection, barrier detection, machine detection, collision detection for protection, point level measurement, and detection of objects or material between two points.

Principle of Operation
A beam of microwave energy passes from a sender unit to a separate receiver in bursts approximately 200 times per second. If the path between the sender and receiver is blocked by any object or material which absorbs or reflects microwave energy, then the receiver will not be able to detect the signal. The presence or absence of the signal at the receiver is used to switch a relay for indication or control purposes.

Certifications
IECEx Zone 20/21, Zone 21
Ex ta tb IIIC T* Da Db Tamb -30°C to +80°C / Tamb = -30°C to +55°C (model dependent)
IP66

State of the art Circular transmission
Backwards compatible with all Gladiator Microwave generations
LCD push button setup / diagnostics on remote amplifier
Simple sensitivity adjustment and calibration on Integral system
Ranges up to 1200 meters (3937 ft)

Primary Areas of Application Liquid Level:
Tank or Vessel

Measuring Range: 10cm (4in) - 1200m (3937ft)
Communications: GosHawk, Modbus, Modbus over Ethernet TCP/IP, 4-20mA
Maximum Operating Pressure: 6 Bar
Mounting: 3.5" male NPT thread or four 10mm (0.4") holes in flange, MA12 / MA13 adjustable mounting bracket
