KELLER LEO1 Digital Pressure Gauge

KELLER LEO1 Digital Pressure Gauge

Product Description


Description

Data



The LEO1 digital manometers have a measuring interval of 5000 individual measurements per second, which allows them to record fast pressure peaks. The minimum or maximum value since the last reset can be displayed at the same time as the current pressure value in a wide variety of units of pressure. Power is supplied by a conventional CR2430 coin cell battery (provided).

  • High accuracy
  • Insulated and encapsulated piezoresistive pressure sensor
  • Energy-efficient: up to 1000 hours of battery life
  • Perfect for recording rapid pressure spikes
  • Optional: Intrinsically safe version LEO1-Ei available for use in hazardous environments
  • Wide range of pressure units to choose from
  • Zero point calibration via button
  • Automatic shutdown
  • Min. / max. display
  • Switchable between standard measurement mode (2 Hz) and rapid measurement mode (5 kHz)



  • Pressure Ranges -1…3 to 0…1000 bar
  • Accuracy ±0,1 %FS
  • Total Error Band ±0,2 %FS @ 0…50 °C
  • Interfaces none
  • Special Characteristics Peak recording
  • Display 4-digit LCD display
