High Overload Gauge Pressure Transmitter 266HSH

High Overload Gauge Pressure Transmitter 266HSH

Product Description


Overview

Fieldbus & HART

Data



266HSH is a high overload gauge pressure transmitter with a maximum working pressure up to 105 MPa, 15225 psi suitable for measuring liquid, gas or steam pressure in a pipe or on an open tank.  Communication options now include Modbus®, along with 4-20mA HART, low-power 1-5V HART, Wireless HART, Profibus, and Foundation Fieldbus.

The 266HSH Modbus® Pressure / Temperature Transmitter is our latest solution to Measurement Made Easy.  This intelligent transmitter provides the user with precise measurements of gauge pressure and optional process temperature (the latter by means of an externally connected Pt100 resistance temperature detector), in a single device.  Information is available to any host device that can communicate using Modbus® protocol.

This transmitter features in-field replaceable electronics module that thanks to the auto-configuration functionality dramatically improves plant productivity. Its intuitive plug-and-play display with easy setup procedure really helps users by saving time and lowering maintenance and inventory costs.
SIL2/SIL3 certification issued by TÜV Nord according to IEC 61508 represents another key-feature within 266 pressure transmitter portfolio. This certification is a real guarantee of protection and makes of 266HSH the smartest fit in Safety-critical loops

This transmitter features in-field replaceable electronics module that thanks to the auto-configuration functionality dramatically improves plant productivity. Its intuitive plug-and-play display with easy setup procedure really helps users by saving time and lowering maintenance and inventory costs.
SIL2/SIL3 certification issued by TÜV Nord according to IEC 61508 represents another key-feature within 266 pressure transmitter portfolio. This certification is a real guarantee of protection and makes of 266HSH the smartest fit in Safety-critical loops

The 266HSH Modbus® Pressure / Temperature Transmitter is our latest solution to Measurement Made Easy.  This intelligent transmitter provides the user with precise measurements of gauge pressure and optional process temperature (the latter by means of an externally connected Pt100 resistance temperature detector), in a single device.  Information is available to any host device that can communicate using Modbus® protocol.

ABB’s freedom of choice offers the right driver for the major fieldbus protocols suitable for ABB devices.
The version matrix document shows for each protocol the software revision that’s compatible to the hardware and firmware revision of the device.
Software and documentation:
HART– Software: DTM, EDD
PROFIBUS– Software: DTM, GSD
FOUNDATION Fieldbus– Software: EDD/CF
Stand-alone tool:ABB offers software tools that use the listed drivers above for your device configuration and monitoring requirements.
Fieldbus solutions:ABB offers a wide range of fieldbus products, accessories, tools, support documentation, applications and news.
  • Base accuracy: from ±0.06%
  • Span limits: 16 to 105000KPa; 64 inH20 to 15228psi
  • Multiple protocol availability – provides integration with Modbus®, HART®, PROFIBUS PA, FOUNDATION Fieldbus and WirelessHART platforms offering interchangeability and transmitter upgrade capabilities
  • Full compliance with PED Category III
